4 Layers Printed Circuit Board Assembly PCB For Control Card Board

Brand Name : HUASWIN
Model Number : HSPCBA1055
Certification : ISO/UL/RoHS
Place of Origin : China
MOQ : 1 sets
Price : Negotiation
Payment Terms : T/T, Western Union, L/C
Supply Ability : 10,000pcs per month
Delivery Time : 15-20 working days
Packaging Details : Anti-static bag + Anti-static bubble wrap + Good quality carton box
Contact Now


4 Layers Printed Circuit Board Assembly PCB assemlby for control card board



Specifications

  1. 15 years experience
  2. customized turnkey solutions
  3. OEM & ODM avaiable
  4. Short lead time & high quality
  5. ISO 9001:2008


Welcome to Huaswin!
Huaswin Electronics is a professional PCB & PCB Assembly manufacturer, located in Shenzhen, China.
We supply one-stop facility services: PCB design, PCB fabrication, components procurement, SMT and DIP
assembly ,IC pre-programming / burning on-line, testing, packing.


PCB capability and services:
1. Single-sided, double-sided & multi-layer PCB (up to 30 layers)
2. Flexible PCB (up to 10 layers)
3. Rigid-flex PCB (up to 8 layers)
4. CEM-1, CEM-3 FR-4, FR-4 High TG, Polyimide, Aluminum-based material.
5. HAL, HAL lead free, Immersion Gold/ Silver/Tin, Hard Gold, OSP surface treatment.
6. Printed Circuit Boards are 94V0 compliant, and adhere to IPC610 Class 2 international PCB standard.
7. Quantities range from prototype to volume production.
8. 100% E-Test


Detailed Specification of PCB Manufacturing

1

layer

1-30 layer

2

Material

CEM-1, CEM-3 FR-4, FR-4 High TG, Polyimide, Aluminum-based material.

3

Board thickness

0.2mm-6mm

4

Max.finished board size

800*508mm

5

Min.drilled hole size

0.25mm

6

min.line width

0.075mm(3mil)

7

min.line spacing

0.075mm(3mil)

8

Surface finish

HAL, HAL Lead free,Immersion Gold/ Silver/Tin, Hard Gold, OSP

9

Copper thickness

0.5-4.0oz

10

Solder mask color

green/black/white/red/blue/yellow

11

Inner packing

Vacuum packing,Plastic bag

12

Outer packing

standard carton packing

13

Hole tolerance

PTH:±0.076,NTPH:±0.05

14

Certificate

UL,ISO9001,ISO14001,ROHS,TS16949

15

Profiling punching

Routing,V-CUT,Beveling


PCB Assembly services:

SMT Assembly
Automatic Pick & Place
Component Placement as Small as 0201
Fine Pitch QEP - BGA
Automatic Optical Inspection
Through-hole Assembly
Wave Soldering
Hand Assembly and Soldering
Material Sourcing
IC pre-programming / Burning on-line
Function testing as requested
Aging test for LED and Power boards
Complete unit assembly (which including plastics, metal box, Coil, cable assembly etc)
Packing design


Conformal coating
Both dip-coating and vertical spray coating is available. Protecting non-conductive dielectric layer that is
applied onto the printed circuit board assembly to protect the electronic assembly from damage due to
contamination, salt spray, moisture, fungus, dust and corrosion caused by harsh or extreme environments.
When coated, it is clearly visible as a clear and shiny material.
Complete box build
Complete 'Box Build' solutions including materials management of all components, electromechanical parts,
plastics, casings and print & packaging material

Testing Methods
AOI Testing
·Checks for solder paste
·Checks for components down to 0201"
·Checks for missing components, offset, incorrect parts, polarity
X-Ray Inspection
X-Ray provides high-resolution inspection of:
·BGAs
·Bare boards
In-Circuit Testing
In-Circuit Testing is commonly used in conjunction with AOI minimizing functional defects caused by
component problems.
· Power-up Test
· Advanced Function Test
· Flash Device Programming
· Functional testing


Detailed Specification of Pcb Assembly

1

Type of Assembly

SMT and Thru-hole

2

Solder Type

Water Soluble Solder Paste,Leaded and Lead-Free

3

Components

Passives Down to 0201 Size

BGA and VFBGA

Leadless Chip Carries/CSP

Double-Sided SMT Assembly

Fine Pitch to 08 Mils

BGA Repair and Reball

Part Removal and Replacement-Same Day Service

3

Bare Board Size

Smallest:0.25x0.25 Inches

Largest:20x20 Inches

4

File Formats

Bill of Materials

Gerber Files

Pick-N-Place File(XYRS)

5

Type of Service

Turn-Key,Partial Turn-Key or Consignment

6

Component Packaging

Cut Tape

Tube

Reels

Loose Parts

7

Turn Time

15 to 20 days

8

Testing

AOI inspection

X-Ray inspection

In-Circuit testing

Functional test
